7
Attach Extension Wands, Tool or Nozzle
Attach Carrying Strap Attach Cord Storage Strap
3
Push hand grip onto
wand or tool so that
button projection fits
into slot.
Turn plastic latch ring
to lock in place.
2
To attach hose to
wand or tool, rotate
plastic latch ring on
hand grip until slots
in opening align.
4
To attach second wand to first or
to attach a tool to wand, fit button
projection into opening in spring
latch. The spring latch will snap
into position.
To release, press down on the spring
latch and remove attachment.
5
To attach carrying strap,
position metal clip on end of
strap into holder provided on
top of cleaner end.
Slip other end of strap through
metal clip already attached to
cleaner, then through buckle.
Adjust strap to desired length.
6
Fasten end of cord storage strap
around cleaner handle, as shown.
Gather cord in strap and fasten
to handle.
