深圳
6
SYS
System
indicator
Blinki
ng
Device connection is
normal
Off
The port is not connected
/ the connection is
abnormal.
LINK/A
CT
Device
connection
indication
Off
Corresponding port is not
connected / the
connection is abnormal.
on
Corresponding device
connection is normal
Rear panel
Includes RJ45 port, power port, reset hole, as shown
below
Port
Name
