Connecting it all together
Unscrew the thumb screws and remove the
energiser top from the battery box.
The energiser can be operated from a 6 or 12v battery. 6v (47P44)batteries t into the
battery box for easy portability. Standard size leisure batteries are run from outside of the
battery box.
If not already inserted, clip the 12v lead into
the connector in the base of the energiser
top.
Position the lead through the slot in the
battery box and replace the energiser top,
securing with the thumb screws.
Connect the croc clips to the battery. If the
energiser beeps, the croc clips are on the
wrong terminals
12v battery connection (external)
7
10
10
