Reservoir
Reservoir Cover
Float Switch Assembly
Red (R)
(upper oat switch)
Black (BK)
(common)
Blue (BU)
(lower oat switch)
Upper Float (blue)
Magnet (towards top)
Magnet (towards top)
Lower Float (white)
Plastic Retainer Clip
Spring Retainer Clip
Fig. 1
Fig. 2
6) Rinse FS assembly thoroughly with clean water and replace in its correct position.
7) Replace the upper rear panel in its correct position.
8) Plug the appliance into the electrical outlet, then move the control switch to the "ICE"
position to start the automatic icemaking process.
Legend: FS–oat switch; LFS–lower oat switch; UFS–upper oat switch
