Hospitex Diagnostics EOS Bravo and EOS Bravo Plus Service Manual
25
N° MNEMONIC DESCRIPTION
SAMPLE
PLATE
32+32
NOTE
IP MOTOR
DEFAULT
VALUE
000 IPNPS0 Inner plate n° position of external ring 32
001 IPNPS1 Inner plate n° position of internal ring 32
002 IPOFS0 Inner plate offset for external ring -20
003 IPOFS1 Inner plate offset for internal ring 22
OP MOTOR
007 OPOFS1 Outer plate2 ring offset sample needle side -333 Only for double cuvette
008 OPOFS0 Outer plate ring offset sample needle side -332
009 OPOFAN Outer plate offset aspiration needle side 23
FS MOTOR
014 FSOFFS Filter selection offset 0
DS MOTOR
018 DSCONV Diluter syringe conversion factor 30086 (step*10ml)
SN MOTOR
021 SNOFFS Sample needle offset 0
022 SNHOME Sample needle home position 0
023 SNHIGH Sample needle height before home, for
rotation over reagent bottles
15
024 SNBOTL Sample needle out of blot paper filter ( not
for rotation)
50
025 SNCUPS Sample needle for sampling on internal
plate: sample/STD cups
190
026 SNTUB Sample needle for sampling on internal
plate: sample/STD tube
363
027 SNDISP Sample needle for dispensation on outer
plate
243
028 SNWASH Sample needle for wash tubes on outer
plate
243
029 SNBUBL Sample needle for R2/R3 and bubbles
dispense on outer plate
270
030 SNBOTL Sample needle on reagent bottles 370
AN MOTOR
034 ANOFFS1 Aspiration probe n°1 offset 0
035 ANOFFS2 Aspiration probe n°2 offset 0 Only for double cuvette
036 ANHIGH Aspiration probe high position in home pos. 25
037 ANWSH1 Aspiration probe wash step 1 160
038 ANWSH2 Aspiration probe wash step 2 170
039 ANDOWN Aspiration probe sampling step for reading 225
PUMP MOTOR
043 PMWSH1 Peristaltic pump wash step 1 650
044 PMWSH2 Peristaltic pump wash step 2 250
045 PMASP1 Peristaltic pump aspiration step 3 cuvette 1 550
046 PMASP2 Peristaltic pump aspiration step 3 cuvette 2 550
047 PMPMOD Peristaltic pump mode 0 0 = Steps
75 = msec (only for double cuv. )
RP MOTOR
049 RPBOT6 Rp motor position of bottle n°1 with rack 6 240
050 RPBOT9 Rp motor position of bottle n°1 with rack 9 245
