The HOTO Flashlight Lite is a versatile and portable lighting device designed for various applications, from daily use to emergency situations. This user manual provides comprehensive information on its features, operation, and maintenance, ensuring users can maximize its potential and ensure its longevity.

Function Description:

The HOTO Flashlight Lite serves as a multi-functional illumination tool, offering different light modes to suit various needs. Its primary function is to provide adjustable brightness for general lighting purposes, with options for low, medium, and high light output. Beyond basic illumination, it incorporates specialized modes like Strobe and SOS, making it a valuable tool for signaling and self-defense in critical situations. The device is equipped with a focus ring that allows users to switch between focused beam and floodlight effects, enhancing its adaptability to different environments and tasks.

Important Technical Specifications:

Model: QWSDT001
Item Dimensions: 164.5 x 30 x 30 mm
Net Weight: Approx. 160 g
Input: 5V-1A
Battery Type: Lithium-ion battery
Battery Capacity: 2600 mAh
Rated Voltage: 3.65V
Charging Time: Approx. 210 min
Brightness (Main Switch Three-Mode Parameters):
- High light mode: 1000LM
- Medium light mode: 350LM
- Low light mode: 50LM
Run Time (Main Switch Three-Mode Parameters):
- High light mode: 2H
- Medium light mode: 3.5H
- Low light mode: 24H
Charging Port: Type-C
Included Accessories: USB charging cable

Usage Features:

The HOTO Flashlight Lite is designed for intuitive and user-friendly operation, incorporating several features that enhance its utility:

Focusing: The flashlight features a focus ring that can be pushed up and down to seamlessly switch between a focused beam and a floodlight effect. This allows users to adjust the light spread according to their specific needs, whether for long-distance illumination or wider area coverage.
Main Switch Operation:
- Daily Use: A short press of the main switch turns the flashlight on in low light mode by default. Subsequent short presses cycle through medium light mode, high light mode, and finally turns the device off. This allows for quick and easy adjustment of brightness.
- During Charging: While charging, a short press of the main switch turns the flashlight on to low light mode, and another short press turns it off.
Strobe/SOS Switch Operation:
- A short press of the Strobe/SOS switch activates the strobe mode.
- Another short press switches to SOS mode.
- A third short press turns the mode off.
- Strobe Mode: This mode provides high-frequency flashing and strong light stimulation, which can be used to disorient potential threats for self-defense.
- SOS Mode: In this mode, the flashlight automatically flashes the internationally recognized SOS signal (three short flashes, three long flashes, three short flashes) to signal for help.
Indicator Light: An indicator light provides clear feedback on the battery status and charging progress:
- Operating Status:
  - Green light on: Battery is above 60%.
  - Orange light on: Battery is between 30%-60%.
  - Red light on: Battery is between 10%-30%.
  - Red light flashes: Battery is less than 10%. (Note: If the red light flashes for a while, the main lamp will flash and turn off in about 2 minutes, indicating the need for charging.)
- Charging Status:
  - Red light breathes: Device is charging.
  - Green light on: Device is fully charged.
Hook: The flashlight includes a hook, providing a convenient way to hang or carry the device, enhancing its portability and accessibility.

Maintenance Features:

To ensure the longevity and safe operation of the HOTO Flashlight Lite, specific maintenance guidelines are provided:

Correct Use: Users are advised to operate the tool strictly according to the instructions provided in the manual to prevent damage and ensure optimal performance.
Maintenance Service: The product is not designed for user disassembly. Any repairs or maintenance should only be performed by personnel authorized by the manufacturer to avoid potential harm and ensure the integrity of the device.
Charging Instructions:
- Only use chargers that comply with the specified charging parameters of the tool. Using incompatible chargers may void the warranty and pose safety risks.
- If the status indicator does not display normally after a long period of disuse, it is recommended to charge the device for 30 minutes and then recheck its status.
Temperature Management:
- After 15 minutes in highlight mode, the flashlight's temperature may increase by approximately 20°C. Users sensitive to temperature should take heat insulation measures. The temperature will gradually decrease after about 25 minutes.
- The product incorporates a charging protection function that stops charging if the battery temperature reaches 45°C. The recommended charging environment temperature is between 0°C and 30°C to ensure safe and efficient charging.
Safety Warnings:
- Avoid directing the strong light into human or animal eyes, or optical equipment lenses, to prevent harm.
- Children should use the flashlight under parental supervision to reduce the risk of harm.
- To prevent electric shock, do not immerse the tool in water or other liquids.
- Do not place or store the tool where it might fall into a bathtub or sink.
- After prolonged use in strobe mode, the focus ring may become hot. Avoid touching it to prevent burns.

By adhering to these guidelines, users can ensure the safe and effective operation of their HOTO Flashlight Lite, extending its lifespan and maximizing its utility.

HOTO Flashlight Lite - Product Overview
