HD516030
Assembly
Adjustment
Loosen inner screws before adjustment making sure they are re-tightened once adjustment
is completed. Note: Further adjustment may be required once baskets are loaded. Screws
fitted in stage 7 will need to be removed before adjustment can be made.
Releasing
Door
Releasing
Runner
Door tilt
Up/Down
Left/Right Door Angle
IMPORTANT: For 5 piece door constructions and Integrated
handle doors, do not place fixing screws through the frame
and into the thin section of the door/handle section.
2
4
5
Repeat this stage
for all five baskets
Fit frame to frontal assembly aligning the bracket.
Lift the front clip carefully
to release
Push the green button
to release and pull out
3
Fit the frame to the
runners
TOP
1.
2.
CLICK
TO
LOCK
CLICK
TO
LOCK
A
1.
2.
3.
B
C D
Screw x4
(4x35mm)
=
1.
2.
3.
