These symbols are used throughout the instruction manual to alert the user to potential
safety hazards as follows :
Warning
…
Notice when incorrect handling could cause the user's death or
serious injury.
Caution
…
Notice when incorrect handling could cause injury to the user or
Material damage.
Even if the instructions do not have
Caution
mark, there are some possibilities for a
serious situation. Follow the instructions.
C-358
BOTTOM BRACKET FIXED CUP TOOL
Thank you for purchasing the HOZAN C-358 BOTTOM BRACKET FIXED CUP TOOL.
With proper care and handling, this fine instrument will provide years of trouble-free
operation. Please read this entire instruction manual carefully before attempting to
place this instrument in service. Please keep this instruction manual available for
reference.
INSTRUCTION MANUAL
Warning and caution symbols
Handle set screw
Cup holder
Stop
Handle
Identification of parts
Specifications
Applicable fixed cups
OAL
Weight
35.8mm, 36.3mm
210mm
1665g
１
