HP 15-cn0100 Maintenance And Service Guide

3. Disconnect the battery cable from the system board (see Battery on page 43).
Remove the solid-state drive:
1. Remove the two Phillips M2.0 × 2.0 screws (1) that secure the drive cover, and then
remove the cover (2).
2. Lift the drive up (1), and then pull it away from the socket to remove it (2).
46 Chapter 5Removal and replacement procedures for authorized service provider parts

HP 15-cn0100 Specifications

General

Brand	HP
Model	15-cn0100
Category	Laptop
Language	English
