Item Component Spare part
number
●
AMD E1-6010 processor and UMA graphics 764267-xxx
●
AMD A6-5200 processor and UMA graphics 760149-xxx
●
AMD A4-5000 processor in models with 2 GB of discrete graphics 760155-xxx
●
AMD A4-5000 processor and UMA graphics 750634-xxx
●
AMD E2-3800 processor and UMA graphics 749659-xxx
●
AMD E1-2100 processor and UMA graphics 750633-xxx
(9) Heat sink assembly (includes replacement thermal materials):
For use in models with an AMD processor, UMA graphics, and 1 memory slot 753895-001
For use in models with an AMD processor, discrete graphics, and 1 memory slot 762728-001
For use in models with an AMD processor, discrete graphics, and 2 memory slots 788561-001
For use in models with an AMD processor, UMA graphics, and 2 memory slots 788562-001
(10) RTC battery 759981-001
(11) Memory module (PC3L, 12800, 1600-MHz):
8-GB 693374-005
4 GB 691740-005
2 GB 691739-005
(12) Hard drive (SATA; does not include bracket):
NOTE: The hard drive bracket is available using spare part number 749648-001.
1-TB, 5400-rpm, 2.5-inch for use in HP 15 and Compaq 15 models 778192-005
750 GB, 5400 rpm hard drive, 2.5 inch for use in HP 15 and Compaq 15 models 778190-005
500-GB, 5400-rpm, 7-mm for use in HP 15 and Compaq 15 models 778186-005
(13) Fan 753894-001
(14) Power connector cable 749647-001
(15) Speakers (includes left and right speakers and cable) 749653-001
(16) Battery:
4-cell, 41-Whr, 2.8-Ah Li-ion battery 740715-001
3-cell, 31-Whr, 2.8-Ah Li-ion battery 746641-001
(17) Base enclosure
For use in defeatured HP 15 and Compaq 15 models 749643-001
For use in full-featured HP 15 and Compaq 15 models 775087-001
(18) Optical drive (DVD+/-RW Double-Layer SuperMulti) 750636-001
18 Chapter 3 Illustrated parts catalog
