Table 3-1 Computer major component descriptions and part numbers (continued)
Item Component Spare part number
(6) Speakers (left and right) M08943-001
(7) USB board
NOTE: The USB board cable is available using spare part number M08870-001.
M16335-001
(8) System board (includes processor)
All system boards use the following part numbers:
xxxxxx-001: Non-Windows operating system
xxxxxx-601: Windows 10 operating system
For use in models with UMA graphics memory:
● Intel Core i7-1165G7 processor M16350-xx1
● Intel Core i5-1135G7 processor M16349-xx1
● Intel Core i3-1115G4 processor M16348-xx1
● Intel Pentium Gold 7505 processor M33440-xx1
For use in models with discrete graphics memory:
● Intel Core i7-1165G7 processor and NVIDIA GeForce MX450 graphics M16346-xx1
● Intel Core i5-1135G7 processor and NVIDIA GeForce MX450 graphics M16345-xx1
● Intel Core i5-1135G7 processor and NVIDIA GeForce MX350 graphics M16344-xx1
(9) Solid-state drive
1 TB, PCIe L85370-005
1 TB solid-state drive + 32 GB Optane memory L85374-005
512 GB, PCIe L85364-005
512 GB solid-state drive + 32 GB Optane memory L85366-005
256 GB, PCIe L85354-005
256 GB solid-state drive + 16 GB Optane memory L85356-005
128 GB, SATA-3, TLC L85346-005
(10) Memory modules (DDR4-3200)
8 GB L46598-005
4 GB L83673-005
(11) WLAN module
Intel Wireless AC-9461 802.11ac 1 × 1 Wi-Fi + Bluetooth 5.1 L25889-005
Intel Wi-Fi 6 AX201 802.11ax 2 × 2 Wi-Fi + Bluetooth 5 (non-vPro) L92724-005
Realtek RTL8822CE 802.11ac 2 × 2 Wi-Fi + Bluetooth 5 L44796-005
(12) Heat sink for use in models with UMA graphics memory (includes replacement thermal material) M08944-001
(13) Fan for use in models with UMA graphics memory M08945-001
Computer major components 17
