Speakers
Description Spare part number
Speaker Kit L20453-001
Before removing the speakers, follow these steps:
1. Shut down the computer.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet and then
unplugging the AC adapter from the computer.
4. Remove the optical drive (see Optical drive on page 33).
5. Remove the bottom cover (see Bottom cover on page 37).
6. Remove the battery (see Battery on page 40).
7. Remove the display (see Display assembly on page 61).
Remove the speakers:
1. Remove the speaker cable from the clips built into the computer (1).
2. Remove the speakers from the computer (2).
Reverse this procedure to install the speakers.
Component replacement procedures 73
