HP 2300d - LaserJet B/W Laser Printer - Power Switch

ENWW Chapter 6 Removal and replacement 123
6 Use a flatblade screwdriver to release one tab (callout 2) at the left side of the top cover.
Figure 48. Removing the top-cover assembly (3 of 3)
7 Lift the cover off of the printer.
2
2
