5
Catalog/System Configuration
Introduction
This chapter provides information on the function of each page of
4
CATALOG/SYSTEM
5 . The following three pages can be called from
4
CATALOG/SYSTEM
5 .
CATALOG
SYSTEM CONFIG
SELF TEST
This chapter describes the functions on each page in the order of the
preceding list of display pages.
CATALOG Page
When you press 4
CATALOG/SYSTEM
5 , the CATALOG page will be
displayed. On this CATALOG page, the catalog of the HP 4284A's
internal memory ( eeprom ) or the external memory card whichis
inserted into the front panel MEMORY card slot, and the following
control functions can be set from this page. (The eld in paren
thesis
is used to set the control function.)
System Menu( SYS MENU )
There are two elds on this page: < CATALOG > and SYS MENU
elds.
The available elds and the softkeys which corresp onded to each eld
on this page are shown in Figure 5-1 and Figure 5-2.
Catalog/System Configuration 5-1
