Figure 6-16. Shorting Plate Connection
Performing LOAD
Correction
To perform LOAD correction data measurement, connect the LOAD
standard to the measurement contacts.
Preparing the Standard
It is necessary to prepare the working standard, such as a standard
resistor and standard capacitor. It is recommended that y
ou select
a standard whose imp edance is as close as possible to DUT's
imp edance. The following are recommendations for selecting
standards.
For capacitance measurements:
A standard capacitor whose capacitance is nearly equal to the
DUT capacitance is recommended.
For resistance measurements:
A standard resistor whose resistance is nearly equal to DUT's
resistance is recommended.
For inductance measurements:
A standard inductor whose inductance is nearly equal to DUT's
inductance is recommended.
Reference Values of the LOAD Standard
Enter sp ecied reference values of the standard as the
REF A
and
REF B
values using the appropreate function on the
CORRECTION
page. For example, When using a standard capacitor which has
a specied parallel capacitance and D v
alues, enter the specied
6-20 Measurement Procedure and Examples
