Mathematical Functions
The deviation and the p ercent of deviation of measurementvalues
from a programmable reference value.
Equivalent Measurement Circuit
Parallel and Series
Ranging
Auto and Manual (Hold/Up/Down)
Trigger
Internal, External, BUS (HP-IB), and Manual.
Delay Time
Programmable delay from the trigger command to the start of the
measurement, 0 to 60.000 sec. in 1 msec. steps.
Measurement terminals
Four-terminal pair
Test Cable Length
Standard.
0 m and 1 m selectable
With Option 006.
0 m, 1 m, 2 m and 4 m selectable
Integration Time
Short, Medium and Long (See Supplemental Performance
Characteristics for the measurement time.)
Averaging
1 to 256, programmable
Test Signal
Frequency
20 Hz to 1 MHz, 8610 selectable frequencies (refer to App endix F for
selectable frequencies.)
Accuracy.
6
0.01%
Signal Modes
Normal.
Programs selected voltage or current at the measurement
terminals when they are op ened or shorted, resp ectively.
Constant.
Maintains selected voltage or current at the device under
test independentofchanges in the device's imp edance.
General Information 9-3
