168 ENWW
6 Open the fuser cover and remove
any media that is crumpled in the
fuser.
Note If the media tears, make sure that
all media fragments are removed from
the paper path before resuming printing.
Do not reach into the fuser until it has
cooled.
7 Firmly press down on the two green
handles on either side of the fuser
to re-engage the fuser rollers.
8 Close the transfer unit and front
cover.
9 Close the top cover.
1
6
1
7
1
8
1
9
