Walk around
The following illustrations identify the locations and names of key
components of this printer.
Front view (shown with second 500-sheet paper feeder)
1. output bin
2. printer control panel
3. top cover
4. front cover (contains Tray 1)
5. Tray 2 (500 sheets of standard paper)
6. Tray 3 (optional; 500 sheets of standard paper)
7. on/off switch
8. access to print cartridges, transfer unit, and fuser
