HP 541 - Page 54

Working Instruction
Document No. :SOP DDD FA Dis-ASS’Y Station
StationStation
Station：
：：
：___________
______________________
___________
Name
NameName
Name：
：：
： Ver
VerVer
Ver.
..
.：
：：
：_____
_____ _____
_____ Date
DateDate
Date：
：：
：___________
______________________
___________
Fixture List(Fixture standard) Qty Fixture List(Fixture standard) Qty
Tabulator：
Issuing department：
IE
Wang Fang
If finding some defects, notice the gaffer and assistant
Points for attention:
30(1/1)
1.00
2007/7/20
Visual inspect M/B
1. Cosmetic inspect
Don’t touch LED lamp when fetching
M/B(Fig.1)
Cable trim clip can’t be dropped(Fig.1)
Check Audio Jack iron dropped or
not(Fig.1)
Check LCM CNTR PIN whether tilted or
broken (Fig.2)
Position for
fetching M/B
Fig.1
LED Lamp
Cable trim
clip
Fig.2
