Remove the system board:
1. Disconnect the optical drive connector cable from the system board.
2. Remove the Phillips PM2.5×6.0 screw (1) that secures the system board to the base enclosure.
3. Lift the right side of the system board (2) until it rests at an angle.
76 Chapter 4 Removal and replacement procedures
