HP 6820s - Page 12

* This device is not intended for use at visual display workplace in compliance with BildscharbV. If this
product is used in an Office Environment where the VDU Directive 90/270/EEC is applicable
(Bildschirmarbeitsverordnung), an external monitor and external keyboard are recommended to avoid
potential reflections.
HP 90W Smart AC
Adapter
Dimensions 5.24 x 2.28 x 1.1 in (13.3 x 5.8 x 2.9 cm)
Weight 0.86 lb (390 g)
Input 100 to 240 VAC
Input Efficiency 83% min at 115 VAC
Input frequency range 47 to 63 Hz
Input AC current 1.5 A at 90 VAC, 0.75 A at 180 VAC PFC
Version
2.4 A at 90 VAC, 1.2 A at 180 VAC NON
PFC Version
Output Output power 90W
DC output 18.5V
Hold-up time 5 msec at 115 VAC input
Output current limit <11A, Over voltage protection- 29V max
automatic shutdown
Connector 3 pin/grounded, mates with interchangeable cords
Environmental Design Operating temperature 32° to 104° F (0° to 40° C)
Non-operating (storage)
temperature
–4° to 149° F (–20° to 65° C)
Altitude 0 to 10,000 ft (0 to 3,048 m)
Humidity 20% to 80%
Storage Humidity 10% to 90%
EMI and Safety
Certifications
CE Mark – full compliance with LVD and EMC directives; Worldwide safety
standards – IEC60950, EN60950, UL60950, Class1, SELV; Agency
approvals – C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class
B, CISPR22 Class B, CCC, NOM-1 NYCE; MTBF- over 200,000 hours at
25°C ambient condition.
6-Cell (55WHr) Lithium-
Ion battery
Dimensions (H x W x L) 0.8 x 2.1 x 8.0 in (2.0 x 5.3 x 20.3 cm)
Weight 0.737 lb (0.335 kg)
Cells/Type 6-cell Lithium-Ion
Energy Watt-hour Capacity 55Wh
Temperature Operating (Charging) 32° to 113° F (0° to 45° C)
Operating (Discharging) 14° to 140° F (–10° to 60° C)
Non-operating –4° to 140° F (–20° to 60° C)
Battery Re-Charge Time System in OFF Mode or
Standby
2.5 hours
System ON 3 to 5 hours (depending on system power
consumption)
QuickSpecs
HP Compaq 6820s Notebook PC
Technical Specifications
DA - 12768 Worldwide QuickSpecs — Version 9 — 4.7.2008 Page 12
