Motherboard
Wiring
List
Introduction
This
table
lists
all
signals
that
are
routed
on
the
A62
motherboard
assembly.
Signals
that
exist
only
on
other assemblies
are
not
shown.
To locate
these,
refer
to
the
pin
I/O
tables
and schematic diagrams
of the
respective assemblies.
The
A62
motherboard
wiring
list
is
arranged so
that signal
mnemonic,
description,
type,
and
level
information
is
on
the
left-hand
page,
and
the
source
and destination information
is
on
the
right-hand
page.
All
mnemonics
are
in
alphabetical
order,
with
power
supplies
listed
at the
end
of the
table.
Unless
otherwise
stated,
all
XA
connector
pins
are
assumed
to
be
part
of their
respective
connector.
For
example,
XA58P1-38
is
written XA58-38
for
simplicity,
with
P1
assumed.
HP 8340B/41B
Motherboard Wiring
List
