5 Adjust the left media guide by
pushing it in (A) and lifting it up and
out (B).
6 Position the guide over the
appropriate media size marked in the
tray.
7 Press the guide into the rear slot (C),
and then lower it down (D) into the
front slot (E). Make sure the guide is
not skewed.
8 Load media into the tray up to the
media-fill mark. For example, up to
500 sheets of 20 lb (75 g/m
2
) bond
paper will fit in the tray. For
information on loading and orienting
media, see the online user’s guide or
the quick reference guide.
Note
Do not fill input trays above the media-fill
mark. Too much media in the input trays
can cause media jams.
26 Step 7: Loading the Input Trays EN
