ES User’s Guide 9-13
Specifications
Table 9-3 System Performance, Corrected, 50Ω, T/R Calibration (continued)
a. These specifications apply for measurements made using “fine” band-
width, no averaging, and at an environmental temperature of
25°±5° C, with less than 1° C deviation from the calibration tempera-
ture.
HP 8712ET/8714ET (50 Ω) without Attenuator
HP 85032B/E (Type-N, 50 Ω) Cal Kit, T/R Calibration
Description
Specification
a
(in dB)
300 kHz
to 1.3 GHz
1.3 GHz
to 3 GHz
Directivity 50 47
Source Match:
Reflection (One-Port Cal) 42 36
Transmission (Enhanced Response Cal) 42 36
Transmission (Response Cal) 23 19
Load Match 18 15
Reflection Tracking
±0.02 ±0.02
Transmission Tracking:
Enhanced Response Cal
±0.039 ±0.052
Response Cal
±0.105 ±0.197
To Next Page
