9-26 ES User’s Guide
Specifications
Table 9-7 Test Port Output (continued)
a. Maximum power setting is the highest power setting allowed that maintains the network
analyzer’s specified level accuracy.
b. Option 1E1 adds a 60 dB step attenuator to the HP 8712ET/8714ET.
HP 8712ET/ES and HP 8714ET/ES Test Port Output
Description Specification
Supplemental
Information
Output Power (continued)
<1 GHz >1 GHz
Maximum Power Setting:
a
HP 8712ET:
50 Ω:
With Attenuator Option 1E1
b
15 dBm 12 dBm
Without Attenuator Option 1E1 16 dBm 13 dBm
75 Ω:
With Attenuator Option 1E1
b
12 dBm 9 dBm
Without Attenuator Option 1E1 13 dBm 10 dBm
HP 8712ES:
50 Ω 13 dBm 10 dBm
75 Ω 10 dBm 7 dBm
HP 8714ET:
50 Ω:
With Attenuator Option 1E1
b
10 dBm 9 dBm
Without Attenuator Option 1E1 11 dBm 10 dBm
75 Ω:
With Attenuator Option 1E1
b
7 dBm 6 dBm at
<2 GHz
6 dBm at >2 GHz,
char.
Without Attenuator Option 1E1 8 dBm 7 dBm at
<2 GHz
7 dBm at >2 GHz,
char.
HP 8714ES:
50 Ω 9 dBm 7 dBm
75 Ω 6 dBm 4 dBm at
<2 GHz
4 dBm at >2 GHz,
char.
