9-40 ES User’s Guide
Specifications
Table 9-9 General Information (continued)
HP 8712ET/ES and HP 8714ET/ES General Information
Description Specification Supplemental Information
System Bandwidths
Wide (6500 Hz) 6500 Hz, nom
Medium Wide (4000 Hz) 4000 Hz, nom
Medium (3700 Hz) 3700 Hz, nom
Medium Narrow (1200 Hz) 1200 Hz, nom
Narrow (250 Hz) 250 Hz, nom
Fine (15 Hz) 15 Hz, nom
Rear Panel
Auxiliary Input:
Connector Female BNC
Impedance 10 kΩ, nom.
Range ±10 V
Accuracy ±3% (reading) + 20 mV
Damage Level >+15 V; <−15 V
External Trigger In/Out: Female BNC; Open-collector
with 681 Ω nom. pullup resistor
to +5 V, nom. Normally high,
pulsed low after each data point
is measured.
Damage Level <−0.2 V; >+5.2 V
Limit Test Output: Female BNC; Open-collector
with 681 Ω nom. pullup resistor
to +5 V, nom. Normally high,
pulled low when limit test fails.
Damage Level <−0.2 V; >+5.2 V
User TTL Input/Output: Female BNC; Open-collector
with 681 Ω nom. pullup resistor
to +5 V nom. Programmable as:
high-sweep output; trigger
input; general I/O for IBASIC.
Damage Level <−0.2 V; >+5.2 V
