Appendix A
hp Server rx2600 Support Management Station
Installing the hp Server rx2600 SMS
141
Connecting the SMS Cables
After the SMS components have been installed, connect them using the following procedure:
NOTE Make sure all devices on the SCSI bus have a unique address and that the last device is
terminated. Refer to the documentation accompanying each device to learn where to place
terminators.
Step 1. Plug the hp Server rx2600, the Tape Array 5300, and the TFT5600 power cords from each unit to
the rack power strip and refer to Figure A-16 for the remaining connections.
