o Disconnecting the cables from the two-bay SFF hot-plug rear drive cage connected to the front drive
cage 2 backplane
o Disconnecting the cables from the two-bay SFF hot-plug rear drive cage connected to the system
board
6. Remove the rear drive cage:
a. Loosen the captive screws to detach the rear drive cage from system board.
b. Loosen the thumbscrews to detach the drive cage from the rear panel.
