EL-MF877-00 Page 2
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Components and parts containing toner and ink,
including liquids, semi-liquids (gel/paste) and toner
Include the cartridges, print heads, tubes, vent
chambers, and service stations.
Components and waste containing asbestos
Components, parts and materials containing
refractory ceramic fibers
Components, parts and materials containing
radioactive substances
List the type and size of the tools that would typically be used to disassemble the product to a point where components
and materials requiring selective treatment can be removed.
Tool Size (if
applicable)
3.0 Product Disassembly Process
3.1 List the basic steps that should typically be followed to remove components and materials requiring selective treatment:
1. Remove Log Low
2. Remove Battery pack
3. Remove FAN & HEAT PIPE
4. Remove Hinge up
5. Remove Motherboard
6. Remove IO PCB
7. Remove Speaker module & K-lock bracket
8. Remove LCD Cover
9. Remove EDP cable / TS / Camera trans / G sensor PCB
10. Remove Antenna
11. Remove Hinge
12. Remove Hinge Cap
3.2 Optional Graphic. If the disassembly process is complex, insert a graphic illustration below to identify the items
contained in the product that require selective treatment (with descriptions and arrows identifying locations).
