HP Color LaserJet CP1210 Series; Color LaserJet CP1510 Series - Page 162

9. Remove two screws (callout 13).
Figure 6-77 Remove the power supply (low-voltage; 8 of 10)
13
10. Pull the power supply away from the chassis (it will not come completely out).
Figure 6-78 Remove the power supply (low-voltage; 9 of 10)
144 Chapter 6 Removal and replacement ENWW
