HP 65W Smart AC
Adapter
Dimensions
4.17 x 1.85 x 1.1 in (10.6 x 4.7 x 2.8 cm)
Weight
0.62 lb (280 g)
Input
100 to 240 VAC
Input Efficiency
83% min at 115 VAC
Input frequency range
47 to 63 Hz
Input AC current
1.7 A at 90 VAC, 0.85 A at 180 VAC
Output
Output power 65W
65W
DC output
18.5V
Hold-up time
5 msec at 115 VAC inputOutput current limit
Output current limit
<11A, Over voltage protection- 29V max
automatic shutdown
Connector
3 pin/grounded, mates with interchangeable cords
Environmental Design
Operating temperature
32° to 104° F (0° to 40° C)
Non-operating (storage)
temperature
–4° to 149° F (–20° to 65° C)
Altitude
0 to 10,000 ft (0 to 3,048 m)
Humidity
20% to 80%
Storage Humidity
10% to 90%
EMI and Safety
Certifications
CE Mark – full compliance with LVD and EMC directives; Worldwide
safety standards – IEC60950, EN60950, UL60950, Class1, SELV;
Agency approvals – C-UL-US, NORDICS, DENAN, EN55022 Class B,
FCC Class B, CISPR22 Class B, CCC, NOM-1 NYCE; MTBF – over
200,000 hours at 25°C ambient condition.
4-Cell (37 WHr)
Lithium-Ion battery
Dimensions
(H x W x L)
0.8 x 2.1 x 8.0 in (2.0 x 5.3 x 20.3 cm)
Weight
0.55 lb (0.249 kg)
Cells/Type
4-cell Lithium-Ion
Energy
Watt-hour Capacity
37 WHr
Temperature
Operating (Charging)
32° to 113° F (0° to 45° C)
Operating (Discharging)
14° to 140° F (–10° to 60° C)
Non-operating
–4° to 140° F (–20° to 60° C)
Battery Re-Charge
Time
System in OFF mode or
Standby
2.5 hours
System ON
3 to 5 hours (depending on system power
consumption)
HP Fast Charge
Technology
Charges the battery up to 90% within 90
minutes when system is OFF
Displays
QuickSpecs
HP Compaq 2230s Notebook PC
Technical Specifications
DA - 13106 Worldwide QuickSpecs — Version 7 — 1/8/2009
Page 13

Other manuals for HP Compaq 2230s

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP Compaq 2230s and is the answer not in the manual?

HP Compaq 2230s Specifications

General IconGeneral
Processor model-
Processor familyIntel® Celeron® M
Processor manufacturerIntel
HDD speed5400 RPM
HDD interfaceSATA
Card reader integratedNo
Total storage capacity120 GB
Display surfaceGloss
Display diagonal12.1 \
Display resolution1280 x 800 pixels
Native aspect ratio16:10
Internal memory4 GB
Memory clock speed800 MHz
Internal memory typeDDR2-SDRAM
Maximum internal memory8 GB
TypePC
Modem speed56 Kbit/s
Internal modemYes
Wireless technology802.11a/b/g/n draft 2.0
Bluetooth version2.0+EDR
Networking featuresMarvell Ethernet (10/100/1000 NIC)
Operating system installedWindows Vista Business
Number of battery cells4
Charging port typeDC-in jack
Serial ports quantity0
USB 2.0 ports quantity3
AC adapter power65 W
Battery performance37 W
Pointing deviceTouchpad + Scroll zone
Country of originChina
Weight and Dimensions IconWeight and Dimensions
Depth294 mm
Height226 mm
Weight1850 g
Height (front)28 mm
