Storage Humidity
10% to 90%
EMI and Safety
Certifications
CE Mark – full compliance with LVD and EMC directives; Worldwide safety
standards – IEC60950, EN60950, UL60950, Class1, SELV; Agency approvals –
C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22 Class B,
CCC, NOM-1 NYCE; MTBF – over 200,000 hours at 25°C ambient condition.
6-Cell (47 WHr) Lithium-
Ion battery
Dimensions
(H x W x L)
0.8 x 2.1 x 8.0 in (2.0 x 5.3 x 20.3 cm)
Weight
0.659 lb (0.299 kg)
Cells/Type
6-cell Lithium-Ion
Energy
Watt-hour Capacity
47 WHr
Temperature
Operating (Charging)
32° to 113° F (0° to 45° C)
Operating (Discharging)
14° to 140° F (–10° to 60° C)
Non-operating
–4° to 140° F (–20° to 60° C)
Battery Re-Charge Time
System in OFF mode or
Standby
2.5 hours
System ON
3 to 5 hours (depending on system power
consumption)
HP Fast Charge Technology
Charges the battery up to 90% within 90 minutes
when system is OFF
Displays
14.0-inch LED HD (1366 x
768)
anti-glare
Active Area
(W x H)
12.16 x 6.85 in (30.9 x17.4 cm)
Diagonal Size
14.0 in (35.6 cm)
Surface Treatment
Anti-glare
Contrast Ratio
300:1 (typical)
Refresh Rate
60 Hz
Brightness
200 nit (typical)
Pixel Resolution
Pitch
0.227 mm
Format
1366 x 768
Configuration
RGB Stripe
Backlight
LED
PPI
112 ppi
Viewing Angle
±30° Horizontal, ±10° Vertical (minimum)
30/30/20/10 (Left/Right/Down/Up) (minimum) or
45/45/35/25 (Left/Right/Down/Up) (typical)
QuickSpecs
Compaq 510 Notebook PC
Compaq 511 Notebook PC
Technical Specifications
DA - 13301 Worldwide — Version 6 — January 7, 2010
Page 14
