Audio
Hardware
Implementation
IDT 92HD75 High Definition audio
Volume Controls
Up, down, and mute function keys
Full Duplex
Yes
Microphone In
Stereo
Headphone/Line Out
Stereo
Integrated Microphone
Yes
Audio Output Quality
Frequency Response
10 Hz ~ 30K Hz
Signal to Noise Ratio
>95 db
Total Harmonic Distortion
>83 dBr
Noise Floor
-110 dB
Play/Record Sampling
Rate
(s)
Up to 192 KHz
DAC
24 bits
ADC
24 bits
Internal Mono Speaker
Power Rating
1.5 W
Impedance
4 ohms
Communications
Integrated Marvell
10/100 NIC
Ethernet Features
10 Mbit/s operation (10BASE-T; IEEE 802.3i; IEEE 802.3 clauses 13-14)
100 Mbit/s operation (100BASE-TX; IEEE 802.3u; IEEE 802.3 clauses 21-30)
Auto-Negotiation (Automatic Speed Selection)
Full Duplex & Half Duplex Operation at all Speeds
IEEE 802.1p QoS (Quality of Service) Support
IEEE 802.3x Flow Control (IEEE 802.3 clauses 31-32; configurable)
Power Management
ACPI compliant – multiple power modes
Situation-sensitive features reduce power consumption
Performance Features
TCP/IP/UDP Checksum Offload (configurable)
Manageability
Wake-on-LAN from standby and hibernation (Magic Packet and Microsoft
Wake-Up Frame); Wake-on-LAN from off (Magic Packet only)
PXE 2.1 Remote Boot
Statistics Gathering (SNMP MIB II, Ethernet-like MIB, Ethernet MIB (802.3x,
clause 30))
Comprehensive diagnostic and configuration software suite
Interface
PCI Express x1
NIC Device Driver Name
Marvell Yukon 88E8042 PCI-E Gigabit Ethernet Controller
QuickSpecs
Compaq 510 Notebook PC
Compaq 511 Notebook PC
Technical Specifications
DA - 13301 Worldwide — Version 6 — January 7, 2010
Page 20
