HP Compaq 515 User Manual

Audio
Hardware Implementation IDT 92HD75 High Definition audio
Volume Controls Up, down, and mute function keys
Full Duplex Yes
Microphone In Stereo
Headphone/Line Out Stereo
Integrated Microphone Yes
Audio Output Quality Frequency Response 10 Hz ~ 30K Hz
Signal to Noise Ratio >95 db
Total Harmonic Distortion >83 dBr
Noise Floor -110 dB
Play/Record Sampling
Rate (s)
Up to 192 KHz
DAC 24 bits
ADC 24 bits
Internal Mono Speaker Power Rating 1.5 W
Impedance 4 ohms
Communications
Integrated Marvell
10/100 NIC
Ethernet Features 10 Mbit/s operation (10BASE-T; IEEE 802.3i; IEEE 802.3 clauses 13-14)
100 Mbit/s operation (100BASE-TX; IEEE 802.3u; IEEE 802.3 clauses 21-30)
Auto-Negotiation (Automatic Speed Selection)
Full Duplex & Half Duplex Operation at all Speeds
IEEE 802.1p QoS (Quality of Service) Support
IEEE 802.3x Flow Control (IEEE 802.3 clauses 31-32; configurable)
Power Management ACPI compliant – multiple power modes
Situation-sensitive features reduce power consumption
Performance Features TCP/IP/UDP Checksum Offload (configurable)
Manageability Wake-on-LAN from standby and hibernation (Magic Packet and Microsoft
Wake-Up Frame); Wake-on-LAN from off (Magic Packet only)
PXE 2.1 Remote Boot
Statistics Gathering (SNMP MIB II, Ethernet-like MIB, Ethernet MIB (802.3x,
clause 30))
Comprehensive diagnostic and configuration software suite
Interface PCI Express x1
QuickSpecs
Compaq 515 Notebook PC
Compaq 516 Notebook PC
Technical Specifications
DA - 13303 North America — Version 6 — January 7, 2010 Page 14

HP Compaq 515 Specifications

General

Operating temperature (T-T)	5 - 35 °C
Battery capacity	47 Wh
Battery life (max)	4 h
Number of battery cells	6
Operating system installed	Windows 7 Home Premium
Operating system architecture	32-bit
HDD speed	5400 RPM
HDD interface	SATA
Optical drive type	DVD Super Multi DL
Card reader integrated	Yes
Total storage capacity	320 GB
Compatible memory cards	SD
Number of HDDs installed	1
Processor model	QL-66
Processor family	AMD Athlon X2 Dual-Core
Processor frequency	2.2 GHz
Processor manufacturer	AMD
Motherboard chipset	-
Display diagonal	14 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Memory slots	2x SO-DIMM
Internal memory	3 GB
Memory clock speed	800 MHz
Internal memory type	DDR2-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	1 x 1 + 1 x 2 GB
Type	PC
Infrared data port	No
Compliance industry standards	IEEE 802.3, IEEE 802.3u
Audio system	HD
Cabling technology	10/100Base-T(X)
Networking features	Fast Ethernet
Charging port type	DC-in jack
USB 2.0 ports quantity	3
Firewire (IEEE 1394) ports	0
Cable lock slot type	Kensington
AC adapter power	65 W
Sustainability certificates	ENERGY STAR
Product color	Black
Country of origin	China
Pointing device	Touchpad + Scroll zone
Discrete graphics card model	AMD Radeon HD 3200

Weight and Dimensions

Depth	234 mm
Width	336 mm
Height	32 mm
Weight	2270 g
