Synchronization Profile (SYNC)
Hard Copy Cable Replacement (HCRP)
1,2
Personal Area Networking Profile (PAN)
1,2
Human Interface Device Profile (HID)
1,2
FAX Profile (FAX)
Basic Imaging Profile (BIP)
2
Headset Profile (HSP)
Hands Free Profile (HFP)
Advanced Audio Distribution Profile (A2DP)
1
indicates the profile is supported by Microsoft Windows XP SP2
2
indicates the profile is part of Windows Vista
Eco Data
Eco-Label Certifications
This product has received or is in the process of being certified to the
following approvals and may be labeled with one or more of these marks:
US Energy Star
IT ECO declaration
EPEAT – Gold
System Configuration
The configuration used for the Energy Consumption and Declared Noise
Emissions data for this model is based on a "Typically Configured Notebook"
Compaq 515 Notebook PC
Energy Consumption
115 VAC 230 VAC 100 VAC
Normal Operation
12.61 W 13.24 W
12.6 W
Sleep (Energy Star low
power mode)
0.61 W
0.6 W
0.57 W
Off
0.91 W 0.94 W 0.91 W
Heat Dissipation*
115 VAC 230 VAC 100 VAC
Normal Operation
43 BTU/hr 45 BTU/hr 43 BTU/hr
Sleep
2 BTU/hr 2 BTU/hr 2 BTU/hr
Off
3 BTU/hr 3 BTU/hr 3 BTU/hr
* Heat dissipation is calculated based on the measured watts, assuming the
service level is attained for one hour.
Declared Noise Emissions
(in accordance with
ISO 7779 and ISO 9296)
System Fan Off
Sound Power
(LWAd, bels)
Sound Pressure
(LpAm, decibels)
Idle
2.8
21.1
Fixed Disk
(random writes)
2.9
22.8
NOTE:
System fan is usually off except when charging the battery
Batteries
This battery(s) in this product comply with EU Directive 2006/66/EC
QuickSpecs
Compaq 515 Notebook PC
Compaq 516 Notebook PC
Technical Specifications
DA - 13303 North America — Version 6 — January 7, 2010
Page 20
