HP Compaq 615 Quickspecs

Pointing device Touchpad with scroll zone, two pick buttons
Expansion Card Slots ExpressCard/34 slot Supports ExpressCard/34
Secure Digital slot Supports SD (Secure Digital), and MultiMediaCard
Storage Hard drives 160/320 GB 5400 rpm SMART SATA
NOTE: Up to 10 GB is reserved for the system recovery software.
DriveGuard The hard drive is mounted directly to the notebook frame, reducing the
transmission of shock to the hard drive.
Fixed optical drives DVD+/-RW SuperMulti DL LightScribe Drive
Interfaces ExpressCard/34 slot Supports ExpressCard/34
External Monitor One - VGA
External Microphone One
Headphone/Line out One
Power Connector One
RJ-11/modem (optional) One
RJ-45/Ethernet One
USB 2.0 Three
LED Status Indicators Six
Audio/Visual High Definition Audio support
Integrated mono speaker
Stereo headphone/line out
Stereo microphone in
Optional integrated 2MP webcam
QuickSpecs
Compaq 615 Notebook PC
Standard Features
DA - 13302 EMEA — Version 7 — January 7, 2010 Page 6

HP Compaq 615 Specifications

General

Graphics	ATI Radeon HD 3200 Graphics
Processor	AMD Athlon X2 Dual-Core Processor
RAM	Up to 8 GB DDR2
Storage	160 GB to 320 GB 5400 rpm SATA
Display	15.6-inch, 1366x768 resolution
Operating System	Windows Vista Business, Windows Vista Home Basic
Battery	6-cell Lithium-Ion
Chipset	AMD M780G
Memory	DDR2 800MHz
Optical Drive	DVD±RW DL LightScribe
Wireless	802.11a/b/g/n
Audio	High Definition Audio support
Ports	3 USB 2.0, VGA, RJ-45, headphone, microphone
Card Reader	5-in-1 (SD, MMC, MS, MS Pro, xD)
Webcam	2 MP Webcam (optional)
Weight	2.49 kg (5.5 lbs)
