HP Compaq 615 User Manual

Hard Drives
320 GB 7200 rpm SATA
Hard Drive
Drive Weight 0.25 lbs (115g)
Capacity 320 GB
Height 0.37 in (9.5 mm)
Width 2.75 in (70 mm)
Interface ATA-8, SATA 2.6, 3.0 Gb/s, NCQ
Transfer Rate Synchronous
(maximum)
100 MB/s (Drive Capability)
Seek Time
(typical reads, including
settling)
Single Track 1.5 ms
Average 11 ms
Maximum 22 ms
Rotational Speed 7200 rpm
Logical Blocks 625,142,448
Operating
Temperature
32° to 140° F (0° to 60° C) [case temp]
Features ATA Security
160 GB 7200 rpm SATA
Hard Drive
Drive Weight 0.25 lbs (115g)
Capacity 160 GB
Height 0.37 in (9.5 mm)
Width 2.75 in (70 mm)
Interface ATA-8, SATA 2.6, 3.0 Gb/s, NCQ
Transfer Rate Synchronous
(maximum)
100 MB/s (Drive Capability)
Seek Time
(typical reads, including
settling)
Single Track 1.5 ms
Average 11 ms
Maximum 22 ms
Rotational Speed 7200 rpm
Logical Blocks 312,581,808
Operating
Temperature
32° to 140° F (0° to 60° C) [case temp]
Features ATA Security
QuickSpecs
Compaq 615 Notebook PC
Technical Specifications
DA - 13302 Worldwide QuickSpecs — Version 5 — 9/15/2009 Page 14

HP Compaq 615 Specifications

General

Graphics	ATI Radeon HD 3200 Graphics
Processor	AMD Athlon X2 Dual-Core Processor
RAM	Up to 8 GB DDR2
Storage	160 GB to 320 GB 5400 rpm SATA
Display	15.6-inch, 1366x768 resolution
Operating System	Windows Vista Business, Windows Vista Home Basic
Battery	6-cell Lithium-Ion
Chipset	AMD M780G
Memory	DDR2 800MHz
Optical Drive	DVD±RW DL LightScribe
Wireless	802.11a/b/g/n
Audio	High Definition Audio support
Ports	3 USB 2.0, VGA, RJ-45, headphone, microphone
Card Reader	5-in-1 (SD, MMC, MS, MS Pro, xD)
Webcam	2 MP Webcam (optional)
Weight	2.49 kg (5.5 lbs)
