V.92 56K Data/Fax
Modem
Form Factor MDC 1.5 Daughtercard
Power Management
Support
APM Revision 1.2, ACPI
Approvals/
Certifications
UL, CSA, NEMKO, CCIB, Industry Canada, FCC Part 68, CTR21, FCC
Part 15 Class B, Canadian ICES-003 Class B, C.I.S.P.R.22, Australian
ACA, CE Mark, Other Countries
Data Mode Capabilities V.92 data
V.8bis
V.80
V44, V.42bis, MNP5 (Compression)
V.42 (LAPM, MNP2-4) (Error Correction)
Optional symbol rates:
2800, 3429
Asymmetric Symbol rates
Synchronous primary channel data signaling rates:
3600, 31200
Automatic rate re-negotiation
V.34
V.32bis
V.32
V.23
V.22bis
V.22
V.21
Bell 212A
Bell 103J
Fax Mode Capabilities TIA/EIA-578-B (Class 1)
T.30, T.4 (Group 3)
V.17
V.29
V.27ter
V.21 Channel 2
Command Set V.250 (Partial)
TIA-602
Identification: +GMI, +GMM, +GMR
Port control: +IPR, +ICF, +IFC, +ILRR
Modulation: +MS, +MR, +MA
Error control: +ES, +ER, +EB, +ESR, +ETBM
Data compression: +DS, +DR
V.251
Broadcom 4312G
802.11b/g WiFi Adapter
Wireless LAN
Standards
IEEE 802.11b
IEEE 802.11g
Interoperability Wi-Fi certified
Cisco Compatible Extensions Program compliantwith Microsoft
Windows Vista and XP (details at:
http://www.hp.com/go/notebooks/WLAN )
Frequency Band 2.4 GHz
Data Rates 802.11b: 1, 2, 5.5, 11 Mbps
802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
QuickSpecs
Compaq 615 Notebook PC
Technical Specifications
DA - 13302 Worldwide QuickSpecs — Version 5 — 9/15/2009 Page 20

HP Compaq 615 Specifications

General

Graphics	ATI Radeon HD 3200 Graphics
Processor	AMD Athlon X2 Dual-Core Processor
RAM	Up to 8 GB DDR2
Storage	160 GB to 320 GB 5400 rpm SATA
Display	15.6-inch, 1366x768 resolution
Operating System	Windows Vista Business, Windows Vista Home Basic
Battery	6-cell Lithium-Ion
Chipset	AMD M780G
Memory	DDR2 800MHz
Optical Drive	DVD±RW DL LightScribe
Wireless	802.11a/b/g/n
Audio	High Definition Audio support
Ports	3 USB 2.0, VGA, RJ-45, headphone, microphone
Card Reader	5-in-1 (SD, MMC, MS, MS Pro, xD)
Webcam	2 MP Webcam (optional)
Weight	2.49 kg (5.5 lbs)
