Hands Free Profile (HFP)
Advanced Audio Distribution Profile (A2DP)
1
indicates the profile is supported by Microsoft Windows XP SP2
2
indicates the profile is part of Windows Vista
Eco Data
Eco-Label
Certifications
This product has received or is in the process of being certified to the
following approvals and may be labeled with one or more of these
marks:
US Energy Star
IT ECO declaration
EPEAT – Gold
System Configuration
The configuration used for the Energy Consumption and Declared
Noise Emissions data for this model is based on a "Typically Configured
Notebook"
Energy Consumption
115 VAC 230 VAC 100 VAC
Normal Operation
12.61 W 13.24 W
12.6 W
Sleep (Energy Star low
power mode)
0.61 W
0.6 W
0.57 W
Off
0.91 W 0.94 W 0.91 W
Heat Dissipation*
115 VAC 230 VAC 100 VAC
Normal Operation
43 BTU/hr 45 BTU/hr 43 BTU/hr
Sleep
2 BTU/hr 2 BTU/hr 2 BTU/hr
Off
3 BTU/hr 3 BTU/hr 3 BTU/hr
* Heat dissipation is calculated based on the measured watts, assuming
the service level is attained for one hour.
Declared Noise
Emissions
(in accordance with
ISO 7779 and ISO 9296)
System Fan Off
Sound Power
(LWAd, bels)
Sound Pressure
(LpAm, decibels)
Idle
3.0
22.6
Fixed Disk
(random writes)
3.1
23
NOTE:
System fan is usually off except when charging the battery
Batteries
This battery(s) in this product comply with EU Directive 2006/66/EC
Batteries used in the product do not contain:
Mercury greater the 5ppm by weight
Cadmium greater than 10ppm by weight
The battery type and chemistry used in the product is:
CR2032 (coin cell), Li ion
6-cell high capacity Li ion battery (optional 8 cell available)
Additional
This product is in compliance with the Restrictions of Hazardous
QuickSpecs
Compaq 615 Notebook PC
Technical Specifications
DA - 13302 Worldwide QuickSpecs — Version 5 — 9/15/2009
Page 25
