HP Compaq 6710b Quickspecs

Communications Integrated Broadcom NetLink Gigabit Ethernet Controller (10/100/1000 NIC)*
56K V.92 modem**
* The term "10/100/1000" or "Gigabit" Ethernet indicates compliance with IEEE standard 802.3ab for
Gigabit Ethernet, and does not connote actual operating speed of 1 Gb/s. For high-speed transmission,
connection to a Gigabit Ethernet server and network infrastructure is required.
** Designed for downloads from 56K modem compliant sources. Maximum achievable download
transmission rates currently do not reach 56 KB/s, and will vary with line conditions. Modem availability is
subject to country regulatory approval.
Wireless Devices Support for a broad range of secure, integrated wireless LAN and wireless WAN options featuring support
for the latest industry standards. Wireless LAN is factory configurable or available as an option to be
added later. Broadband Wireless (WWAN) requires Windows Vista Business or Windows XP Professional
and is available in select countries as a standard, factory configurable feature only. Integrated Bluetooth is
also available (factory configurable only) and can be combined with any of the supported wireless LAN and
wireless WAN options.
HP ev2200 1xEV-DO
Broadband Wireless
Module
Integrated WWAN module connects to the Verizon Wireless BroadbandAccess
and NationalAccess networks (U.S. only)
Supports CDMA 1xEV-DO, 1xRTT connections at 850 and 1900 MHz.
NOTE: Separately purchased Verizon Wireless service is required. For details,
go to http://www.hp.com/go/broadbandwireless .
Two 850/900/1800/1900/2100-MHz antennas integrated in the top of the
display panel support current and future WWAN technologies
HP hs2300 HSDPA
Broadband Wireless
Module
Integrated WWAN module that provides connection to GSM, GPRS, EDGE,
UMTS, and HSDPA mobile networks in many countries. Currently available for
the AT&T Broadbandconnect network in the U.S. (supports international
roaming).
NOTE: Separately purchased mobile network operator service is required.
Two 850/900/1800/1900/2100-MHz antennas integrated in the top of the
display panel support current and future WWAN technologies.
All 802.11a/b/g
integrated wireless LAN
options
Wi-Fi certified
Cisco Compatible Extensions support (Version 4.0) with Microsoft Windows XP
Wired Equivalent Privacy (WEP) support up to 128-bit keys
Wi-Fi Protected Access (WPA) and WPA2 support
802.1x authentication support, including EAP-TLS, EAP-TTLS, PEAP-GTC,
PEAP-MSCHAPv2, and LEAP
Advanced Encryption Standard (AES) support
WiFi certified for WPA2, WMM
Dual antennas integrated in the display enclosure
Intel Wireless WiFi Link
4965AGN*
Integrated support for 802.11a, b, g, and draft-n
Up to 300-mbps data rate
Intel Wireless WiFi Link
4965AG*
Integrated support for 802.11 a, b and g
Up to 54-mbps data rate
Intel PRO/Wireless
3945ABG Network
Connection*
Integrated support for 802.11 a, b and g
Up to 54-mbps data rate
QuickSpecs
HP Compaq 6710b Notebook PC
Standard Features
DA - 12685 North America — Version 13 — March 18, 2008 Page 5

HP Compaq 6710b Specifications

General

Operating temperature (T-T)	0 - 35 °C
Operating relative humidity (H-H)	10 - 90 %
Discrete graphics card	Yes
Discrete graphics card model	Intel® GMA X3100
Maximum graphics card memory	0.384 GB
Bus type	FSB
Stepping	M0
Tjunction	105 °C
Processor cache	3 MB
Processor cores	2
Processor model	T8300
System bus rate	- GT/s
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo T8000 Series
Processor socket	Socket 479
Processor codename	Penryn
Processing Die size	107 mm²
Processor frequency	2.4 GHz
Processor cache type	L2
Processor lithography	45 nm
Processor system type	Up
Processor manufacturer	Intel
Processor front side bus	800 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	12
Number of Processing Die Transistors	410 M
HDD speed	5400 RPM
HDD interface	SATA
Optical drive type	DVD Super Multi DL
Card reader integrated	-
Total storage capacity	160 GB
Number of HDDs installed	1
Operating system installed	Windows Vista Business
Operating system architecture	32-bit
Display diagonal	15.4 \
Display resolution	- pixels
Memory slots	2x SO-DIMM
Memory upgrade	4 GB
Internal memory	2 GB
Memory clock speed	667 MHz
Internal memory type	DDR2-SDRAM
Type	PC
Modem speed	56 Kbit/s
Power supply type	AC/DC
Wireless technology	Wi-Fi
Compatible operating systems	Windows Vista
Motherboard chipset	Intel® GM965
Audio system	HD
Pointing device	Touchpad + Scroll zone
Bluetooth version	2.0+EDR
TV-out type	S-Video
Charging port type	DC-in jack
HDMI ports quantity	0
USB 2.0 ports quantity	4
Cable lock slot type	Kensington
Battery capacity	55 Wh
Battery life (max)	5.1 h
Number of battery cells	6
AC adapter power	90 W
Product color	Black
Country of origin	China
Processor code	SLAPR
Processor ARK ID	33099
Processor package size	35 x 35 mm

Weight and Dimensions

Depth	265 mm
Width	357 mm
Weight	2600 g
Height (front)	34 mm
