HP Compaq 6710b Quickspecs

Storage Hard drives 80/120/160-GB 5400 rpm SMART SATA
80/120-GB 7200 rpm SMART SATA
NOTE: These hard drives are customer removable and will withstand multiple insertion/removal cycles. Up
to 10 GB is reserved for the system recovery software.
HP 3D DriveGuard The hard drive is mounted directly to the notebook frame, reducing the
transmission of shock to the hard drive. Uses three-axis digital motion
detection with intelligent sensitivity to help protect the hard drive during
normal use from shock and vibration. The digital accelerometer temporarily
halts all data transfer and parks the hard drive when abrupt motion is
detected.
Fixed optical drives DVD/CD-RW Combo Drive
DVD+/-RW SuperMulti DL Drive
DVD+/-RW SuperMulti DL LightScribe Drive
Interfaces PC Card slot One Type I/II PC Card slot or optional Smart Card Reader
External monitor One – VGA
1394a One
Stereo microphone in One
Stereo headphone/line
out
One
Power connector One
RJ-11/modem One
RJ-45/Ethernet One
S-video TV out One (Support for NTSC/PAL)
USB 2.0 Four
Docking connector One
Secondary battery
connector
One
LED status indicators Fifteen
Audio High Definition Audio support w/24-bit DAC
Integrated stereo speakers
Integrated microphone
Touch-sensitive controls for volume up, volume down, and mute
Stereo headphone/line out
Stereo microphone in
QuickSpecs
HP Compaq 6710b Notebook PC
Standard Features
DA - 12685 North America — Version 13 — March 18, 2008 Page 7

HP Compaq 6710b Specifications

General

Operating temperature (T-T)	0 - 35 °C
Operating relative humidity (H-H)	10 - 90 %
Discrete graphics card	Yes
Discrete graphics card model	Intel® GMA X3100
Maximum graphics card memory	0.384 GB
Bus type	FSB
Stepping	M0
Tjunction	105 °C
Processor cache	3 MB
Processor cores	2
Processor model	T8300
System bus rate	- GT/s
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo T8000 Series
Processor socket	Socket 479
Processor codename	Penryn
Processing Die size	107 mm²
Processor frequency	2.4 GHz
Processor cache type	L2
Processor lithography	45 nm
Processor system type	Up
Processor manufacturer	Intel
Processor front side bus	800 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	12
Number of Processing Die Transistors	410 M
HDD speed	5400 RPM
HDD interface	SATA
Optical drive type	DVD Super Multi DL
Card reader integrated	-
Total storage capacity	160 GB
Number of HDDs installed	1
Operating system installed	Windows Vista Business
Operating system architecture	32-bit
Display diagonal	15.4 \
Display resolution	- pixels
Memory slots	2x SO-DIMM
Memory upgrade	4 GB
Internal memory	2 GB
Memory clock speed	667 MHz
Internal memory type	DDR2-SDRAM
Type	PC
Modem speed	56 Kbit/s
Power supply type	AC/DC
Wireless technology	Wi-Fi
Compatible operating systems	Windows Vista
Motherboard chipset	Intel® GM965
Audio system	HD
Pointing device	Touchpad + Scroll zone
Bluetooth version	2.0+EDR
TV-out type	S-Video
Charging port type	DC-in jack
HDMI ports quantity	0
USB 2.0 ports quantity	4
Cable lock slot type	Kensington
Battery capacity	55 Wh
Battery life (max)	5.1 h
Number of battery cells	6
AC adapter power	90 W
Product color	Black
Country of origin	China
Processor code	SLAPR
Processor ARK ID	33099
Processor package size	35 x 35 mm

Weight and Dimensions

Depth	265 mm
Width	357 mm
Weight	2600 g
Height (front)	34 mm
