HP Compaq 6710b User Manual

Spare part
number
Description
443811-DJ1 Keyboard for use in Greece
443812-001 15.4-inch WXGA, BrightView display assembly for use with HP Compaq 6715s and 6710s computer models
443813-001 15.4-inch WSXGA+ display assembly for use with HP Compaq 6715b and 6710b computer models without
WWAN capability
443814-001 15.4-inch WSXGA+ display assembly for use with HP Compaq 6715b and 6710b computer models with
WWAN capability
443815-001 15.4-inch WSXGA+ display assembly for use with HP Compaq 6715b and 6710b computer models without
WWAN capability
443816-001 15.4-inch WXGA, BrightView display assembly for use with HP Compaq 6715b and 6710b computer models
without WWAN capability
443817-001 15.4-inch WXGA, BrightView display assembly for use with HP Compaq 6715b and 6710b computer models
with WWAN capability
443818-001 15.4-inch WSXGA+ display assembly for use with HP Compaq 6715s and 6710s computer models
443819-001 15.4-inch WXGA display assembly for use with HP Compaq 6715s and 6710s computer models
443820-001 Optical drive connector board
443821-001 Speaker assembly
443822-001 Top cover for use with HP Compaq 6715b and 6710b computer models (includes TouchPad, TouchPad cable,
and fingerprint reader)
443823-001 Top cover for use with HP Compaq 6715s and 6710s computer models (includes TouchPad and TouchPad cable)
443883-001 USB/Media Card Reader board––for use with HP Compaq 6715b and 6710b computer models (includes USB/
Media Card Reader board cable)
443884-001 6-cell, 2.20-Ah, 47-Wh battery
443885-001 6-cell, 2.55-Ah, 55-Wh battery
443887-001 Cable Kit
443888-001 PC Card/audio board assembly for use with HP Compaq 6715s and 6710s computer models
443889-001 PC Card/audio board assembly for use with HP Compaq 6715b and 6710b computer models (includes 1394
port)
443890-001 AMD Turion TL-52 1.6-GHz processor for use with HP Compaq 6715 computer models only in Japan and Asia/
Pacific countries and regions (1-MB L2 cache)
443891-001 AMD Turion TL-56 1.8-GHz processor for use only with HP Compaq 6715 computer models only in Japan and
Asia/Pacific countries and regions (1-MB L2 cache)
443892-001 AMD Turion TL-60 2.0-GHz processor for use only with HP Compaq 6715 computer models only in Japan and
Asia/Pacific countries and regions (1-MB L2 cache)
443896-001 System board for use with HP Compaq 6715b computer models with WWAN capability (includes WWAN
module slot)
443897-001 System board for use with HP Compaq 6715s computer models
443898-001 System board for use with HP Compaq 6715b computer models without WWAN capability (does not include
WWAN module slot)
443901-001 DVD/CD-RW Combo Drive
443902-001 DVD-ROM drive
38 Chapter 3 Illustrated parts catalog ENWW

HP Compaq 6710b Specifications

General

Operating temperature (T-T)	0 - 35 °C
Operating relative humidity (H-H)	10 - 90 %
Discrete graphics card	Yes
Discrete graphics card model	Intel® GMA X3100
Maximum graphics card memory	0.384 GB
Bus type	FSB
Stepping	M0
Tjunction	105 °C
Processor cache	3 MB
Processor cores	2
Processor model	T8300
System bus rate	- GT/s
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo T8000 Series
Processor socket	Socket 479
Processor codename	Penryn
Processing Die size	107 mm²
Processor frequency	2.4 GHz
Processor cache type	L2
Processor lithography	45 nm
Processor system type	Up
Processor manufacturer	Intel
Processor front side bus	800 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	12
Number of Processing Die Transistors	410 M
HDD speed	5400 RPM
HDD interface	SATA
Optical drive type	DVD Super Multi DL
Card reader integrated	-
Total storage capacity	160 GB
Number of HDDs installed	1
Operating system installed	Windows Vista Business
Operating system architecture	32-bit
Display diagonal	15.4 \
Display resolution	- pixels
Memory slots	2x SO-DIMM
Memory upgrade	4 GB
Internal memory	2 GB
Memory clock speed	667 MHz
Internal memory type	DDR2-SDRAM
Type	PC
Modem speed	56 Kbit/s
Power supply type	AC/DC
Wireless technology	Wi-Fi
Compatible operating systems	Windows Vista
Motherboard chipset	Intel® GM965
Audio system	HD
Pointing device	Touchpad + Scroll zone
Bluetooth version	2.0+EDR
TV-out type	S-Video
Charging port type	DC-in jack
HDMI ports quantity	0
USB 2.0 ports quantity	4
Cable lock slot type	Kensington
Battery capacity	55 Wh
Battery life (max)	5.1 h
Number of battery cells	6
AC adapter power	90 W
Product color	Black
Country of origin	China
Processor code	SLAPR
Processor ARK ID	33099
Processor package size	35 x 35 mm

Weight and Dimensions

Depth	265 mm
Width	357 mm
Weight	2600 g
Height (front)	34 mm
