HP Compaq 6720s User Manual

1.
2.
3.
4.
5.
Dimensions 0.19 x 1.2 x 2.0 in (4.75 x 29.85 x 50.8 mm)
Operating Voltage 3.3V +/- 9%, 1.5V +/- 5%
Temperature Operating
Non-operating
32° to 176° F (0° to 80° C)
–40° to 176° F (–40° to 80° C)
Humidity Operating
Non-operating
10% to 90% (non-condensing)
5% to 90% (non-condensing)
Altitude Operating
Non-operating
0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)
Configuration Utility
5
Microsoft Windows 2000 or XP
Choice of Configuration Utility:
Microsoft Windows XP Wireless Network Connection Manager
Intel PROSet for Microsoft Windows 2000 or XP (required for Cisco
Compatible Extensions support)
Microsoft Windows Vista
Microsoft Windows Vista Wireless Network Connection Manager
LED Activity LED Off – Radio OFF; Solid LED On – Radio ON
Check latest software/driver release for updates on supported security features.
Maximum output power may vary by country according to local regulations.
In Power Save Polling mode and on battery power.
Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and a
packet error rate of 10% for 802.11a/g (OFDM modulation).
WLAN supplier's client utility is required for Cisco Compatible Extensions support with Microsoft
Windows 2000 or XP. WLAN may also be compatible with certain third-party software supplicants.
Broadcom 4311AG
802.11a/b/g WiFi Adapter
Wireless LAN Standards IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
Interoperability Wi-Fi certified
Cisco Compatible Extensions Program compliant with Microsoft Windows
2000 and XP (details at http://www.hp.com/go/notebooks/WLAN )
Frequency Band 2.4 GHz and 5 GHz
Data Rates 802.11b: 1, 2, 5.5, 11 Mbps
802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
Modulation Direct Sequence Spread Spectrum
DBPSK, DQPSK, CCK, OFDM
Security
1
Supports 64- and 128-bit WEP, WPA, WPA2, hardware-accelerated AES,
802.1x authentication types EAP-TLS, EAP-TTLS, PEAP-GTC, PEAP-MSCHAPv2,
LEAP, EAP-FAST.
Support for Cisco Security Features (proven compatibility with Cisco Aironet
infrastructure products through the Cisco Compatible Extensions Program
Version 4).
Sub-channels Multinational support with frequency bands and channels compliant to local
regulations.
QuickSpecs
HP Compaq 6720s Notebook PC
Technical Specifications
DA - 12759 North America — Version 11 — May 8, 2008 Page 25

HP Compaq 6720s Specifications

General

Bus type	FSB
Stepping	M0
Tjunction	105 °C
Processor cache	3 MB
Processor cores	2
Processor model	T8100
System bus rate	- GT/s
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo T8000 Series
Processor socket	Socket 478
Processor codename	Penryn
Processing Die size	107 mm²
Processor frequency	2.1 GHz
Processor cache type	L2
Processor lithography	45 nm
Processor manufacturer	Intel
Processor front side bus	800 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	10.5
Number of Processing Die Transistors	410 M
HDD speed	5400 RPM
HDD interface	SATA
Card reader integrated	Yes
Total storage capacity	120 GB
Compatible memory cards	SD
Display diagonal	15.4 \
Display resolution	1280 x 800 pixels
Native aspect ratio	16:10
Internal memory	1 GB
Memory clock speed	667 MHz
Internal memory type	DDR2-SDRAM
Maximum internal memory	4 GB
Discrete graphics card model	Intel® GMA X3100
Maximum graphics card memory	0.384 GB
Type	PC
Modem speed	56 Kbit/s
Wireless technology	802.11a/b/g
Audio system	High Definition Audio
Networking features	Fast Ethernet, WLAN
Operating system installed	Windows Vista Business
Number of battery cells	6
Charging port type	DC-in jack
Serial ports quantity	0
USB 2.0 ports quantity	3
CardBus PCMCIA slot type	Type II
Cable lock slot type	Kensington
Operating temperature (T-T)	0 - 35 °C
Operating relative humidity (H-H)	10 - 90 %
Non-operating relative humidity (non-condensing)	5 - 95 %
AC adapter power	65 W
Pointing device	Touchpad
Processor code	SLAVJ
Processor ARK ID	33916
Processor package size	35 x 35 mm
Country of origin	China

Weight and Dimensions

Depth	267 mm
Width	358 mm
Height	32 mm
Weight	2500 g
