HP Compaq 6720s User Manual

Environmental Data Eco-Label Certifications This product has received or is in the process of being certified to the following
approvals and may be labeled with one or more of these marks:
ENERGY STAR 4.0
US Federal Energy Management Program (FEMP)
ECO declaration
Taiwan Green Mark
China Energy Certification Program (CECP)
Korean Eco Label
EPEAT Silver Rating
System Configuration The configuration used for the Energy Consumption and Declared Noise
Emissions data is based on a “Typically Configured Notebook”
Energy Consumption 115 VAC 230 VAC 100 VAC
Normal Operation 18.6 W 18.9 W 18.8 W
Sleep (Energy Star low
power mode)
1 W 1.1 W 0.99 W
Off 0.9 W 1.01 W 0.9 W
Heat Dissipation* 115 VAC 230 VAC 100 VAC
Normal Operation 63.463 BTU/hr 64.486 BTU/hr 64.145 BTU/hr
Sleep 3.412 BTU/hr 3.753 BTU/hr 3.377 BTU/hr
Off 3.07 BTU/hr 3.446 BTU/hr 3.07 BTU/hr
* Heat dissipation is calculated based on the measured watts, assuming the
service level is attained for one hour.
This product is in compliance with US executive order 13221, WOL (wake on
LAN) disabled.
Declared Noise Emissions
(in accordance with ISO
7779 and ISO 9296)
Sound Power
(LWAd, bels)
Sound Pressure
(LpAm, decibels)
Idle 3.4 27.3
Operating mode (HDD) 3.4 27.4
Batteries This product complies with ISO standards:
EU Directive 91/ 157/ EEC
EU Directive 93/ 86/ EEC
EU Directive 98/ 101/ EEC
Batteries used in the product do not contain:
Mercury greater the 5ppm by weight
Cadmium greater than 10ppm by weight
Lead greater than 4000 ppm by weight.
The battery type and chemistry used in the product is:
CR2032 (coin cell), Lithium
6 cell rechargeable Lithium-Ion battery
Additional This product is in compliance with the EU Restrictions of Hazardous
QuickSpecs
HP Compaq 6720s Notebook PC
Technical Specifications
DA - 12759 North America — Version 11 — May 8, 2008 Page 29

HP Compaq 6720s Specifications

General

Bus type	FSB
Stepping	M0
Tjunction	105 °C
Processor cache	3 MB
Processor cores	2
Processor model	T8100
System bus rate	- GT/s
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo T8000 Series
Processor socket	Socket 478
Processor codename	Penryn
Processing Die size	107 mm²
Processor frequency	2.1 GHz
Processor cache type	L2
Processor lithography	45 nm
Processor manufacturer	Intel
Processor front side bus	800 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	10.5
Number of Processing Die Transistors	410 M
HDD speed	5400 RPM
HDD interface	SATA
Card reader integrated	Yes
Total storage capacity	120 GB
Compatible memory cards	SD
Display diagonal	15.4 \
Display resolution	1280 x 800 pixels
Native aspect ratio	16:10
Internal memory	1 GB
Memory clock speed	667 MHz
Internal memory type	DDR2-SDRAM
Maximum internal memory	4 GB
Discrete graphics card model	Intel® GMA X3100
Maximum graphics card memory	0.384 GB
Type	PC
Modem speed	56 Kbit/s
Wireless technology	802.11a/b/g
Audio system	High Definition Audio
Networking features	Fast Ethernet, WLAN
Operating system installed	Windows Vista Business
Number of battery cells	6
Charging port type	DC-in jack
Serial ports quantity	0
USB 2.0 ports quantity	3
CardBus PCMCIA slot type	Type II
Cable lock slot type	Kensington
Operating temperature (T-T)	0 - 35 °C
Operating relative humidity (H-H)	10 - 90 %
Non-operating relative humidity (non-condensing)	5 - 95 %
AC adapter power	65 W
Pointing device	Touchpad
Processor code	SLAVJ
Processor ARK ID	33916
Processor package size	35 x 35 mm
Country of origin	China

Weight and Dimensions

Depth	267 mm
Width	358 mm
Height	32 mm
Weight	2500 g
