HP Compaq 6720s User Manual

Processors Intel Core 2 Duo Processor T8100 (2.10 GHz, 800 MHz FSB, 3 MB L2 cache) *
Intel Core 2 Duo Processor T5870 (2.0-GHz, 800-MHz FSB, 2-MB L2 cache) *
Intel Core 2 Duo Processor T5670 (1.8-GHz, 800- MHz FSB, 2-MB L2 cache) *
Intel Core 2 Duo Processor T5470 (1.60-GHz, 800-MHz FSB, 2-MB L2 cache) *
Intel Celeron Processor 550 (2.0-GHz, 533-MHz FSB, 1-MB L2 cache) *
* Intel's numbering is not a measurement of higher performance.
NOTE: Processor speed denotes maximum performance mode; processors will run at lower speeds in
battery optimization mode.
Operating System Preinstalled Genuine Windows Vista Business 32 *
Genuine Windows Vista Downgrade to Windows XP Professional *+
Genuine Windows Vista Home Basic 32 *
Genuine Windows XP Professional
FreeDOS
Supported Genuine Windows XP Professional
Certified SuSe Linux Enterprise Desktop 10
* Certain Windows Vista product features require advanced or additional hardware. See:
http://www.microsoft.com/windowsvista/getready/hardwarereqs.mspx and:
http://www.microsoft.com/windowsvista/getready/capable.mspx for details. Windows Vista Upgrade
Advisor can help you determine which features of Windows Vista will run on your computer. To download
the tool, visit: http://www.windowsvista.com/upgradeadvisor .
+ Windows Vista Business disk also included for future upgrade if desired. To qualify for this downgrade an
end user must be a business (including governmental or educational institutions) and is expected to order
annually at least 25 customer systems with the same custom image.
Chipset Mobile Intel GME965 Express Chipset (ships with Intel Core 2 Duo Processors) or
Mobile Intel GLE960 Express Chipset (ships with Intel Celeron Processors)
Graphics Mobile Intel Graphics Media Accelerator X3100, up to 384-MB shared system memory
Microsoft DirectX 9 capable
Display Internal 15.4-inch diagonal WXGA anti-glare (1280 x 800 resolution)
15.4-inch diagonal WXGA BrightView (1280 x 800 resolution)
External Up to 32-bit per pixel color depth
VGA port supports resolutions up to 2048 x 1536 at 75 Hz, and lower
resolutions at up to 100 Hz
NOTE: Resolutions are dependent upon monitor capability, and resolution and
color depth settings.
QuickSpecs
HP Compaq 6720s Notebook PC
Standard Features
DA - 12759 North America — Version 11 — May 8, 2008 Page 3

HP Compaq 6720s Specifications

General

Bus type	FSB
Stepping	M0
Tjunction	105 °C
Processor cache	3 MB
Processor cores	2
Processor model	T8100
System bus rate	- GT/s
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo T8000 Series
Processor socket	Socket 478
Processor codename	Penryn
Processing Die size	107 mm²
Processor frequency	2.1 GHz
Processor cache type	L2
Processor lithography	45 nm
Processor manufacturer	Intel
Processor front side bus	800 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	10.5
Number of Processing Die Transistors	410 M
HDD speed	5400 RPM
HDD interface	SATA
Card reader integrated	Yes
Total storage capacity	120 GB
Compatible memory cards	SD
Display diagonal	15.4 \
Display resolution	1280 x 800 pixels
Native aspect ratio	16:10
Internal memory	1 GB
Memory clock speed	667 MHz
Internal memory type	DDR2-SDRAM
Maximum internal memory	4 GB
Discrete graphics card model	Intel® GMA X3100
Maximum graphics card memory	0.384 GB
Type	PC
Modem speed	56 Kbit/s
Wireless technology	802.11a/b/g
Audio system	High Definition Audio
Networking features	Fast Ethernet, WLAN
Operating system installed	Windows Vista Business
Number of battery cells	6
Charging port type	DC-in jack
Serial ports quantity	0
USB 2.0 ports quantity	3
CardBus PCMCIA slot type	Type II
Cable lock slot type	Kensington
Operating temperature (T-T)	0 - 35 °C
Operating relative humidity (H-H)	10 - 90 %
Non-operating relative humidity (non-condensing)	5 - 95 %
AC adapter power	65 W
Pointing device	Touchpad
Processor code	SLAVJ
Processor ARK ID	33916
Processor package size	35 x 35 mm
Country of origin	China

Weight and Dimensions

Depth	267 mm
Width	358 mm
Height	32 mm
Weight	2500 g
