HP Compaq 6720s User Manual

Keyboard The 101/102-key compatible keyboard features an industry standard, full-pitch key layout with desktop
keyboard features, such as the isolated inverted-T cursor control keys, editing keys, both left and right
control and alt keys, and 12 function keys. US and International key layouts are available. Other features
include an integrated numeric keypad, hotkeys for instant access to power conservation, brightness, and
other features, 19-mm x 19-mm key pitch (center-to-center spacing), 2.5-mm stroke, and comfort-dished
keycaps.
Pointing device Touchpad with scroll zone, two pick buttons
Expansion card slots
ExpressCard/54 slot Supports ExpressCard/54 and ExpressCard/34
Secure Digital slot Supports SD (Secure Digital), Multimedia card
Storage Hard drives 120/160/250-GB 5400 rpm SMART SATA
NOTE: These hard drives are customer removable and will withstand multiple insertion/removal cycles. Up
to 10 GB is reserved for the system recovery software.
HP DriveGuard The hard drive is mounted directly to the notebook frame, reducing the
transmission of shock to the hard drive.
Fixed optical drives DVD/CD-RW Combo Drive
DVD+/-RW SuperMulti DL LightScribe Drive
Interfaces ExpressCard/54 Supports ExpressCard/54 and ExpressCard/34
External monitor One – VGA
Stereo microphone in One
Stereo headphone/line
out
One
Power connector One
RJ-11/modem One
RJ-45/Ethernet One
USB 2.0 Three
LED status indicators Six
Audio High Definition Audio support
Integrated mono speaker
Stereo headphone/line out
Stereo microphone in
QuickSpecs
HP Compaq 6720s Notebook PC
Standard Features
DA - 12759 North America — Version 11 — May 8, 2008 Page 5

HP Compaq 6720s Specifications

General

Bus type	FSB
Stepping	M0
Tjunction	105 °C
Processor cache	3 MB
Processor cores	2
Processor model	T8100
System bus rate	- GT/s
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo T8000 Series
Processor socket	Socket 478
Processor codename	Penryn
Processing Die size	107 mm²
Processor frequency	2.1 GHz
Processor cache type	L2
Processor lithography	45 nm
Processor manufacturer	Intel
Processor front side bus	800 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	10.5
Number of Processing Die Transistors	410 M
HDD speed	5400 RPM
HDD interface	SATA
Card reader integrated	Yes
Total storage capacity	120 GB
Compatible memory cards	SD
Display diagonal	15.4 \
Display resolution	1280 x 800 pixels
Native aspect ratio	16:10
Internal memory	1 GB
Memory clock speed	667 MHz
Internal memory type	DDR2-SDRAM
Maximum internal memory	4 GB
Discrete graphics card model	Intel® GMA X3100
Maximum graphics card memory	0.384 GB
Type	PC
Modem speed	56 Kbit/s
Wireless technology	802.11a/b/g
Audio system	High Definition Audio
Networking features	Fast Ethernet, WLAN
Operating system installed	Windows Vista Business
Number of battery cells	6
Charging port type	DC-in jack
Serial ports quantity	0
USB 2.0 ports quantity	3
CardBus PCMCIA slot type	Type II
Cable lock slot type	Kensington
Operating temperature (T-T)	0 - 35 °C
Operating relative humidity (H-H)	10 - 90 %
Non-operating relative humidity (non-condensing)	5 - 95 %
AC adapter power	65 W
Pointing device	Touchpad
Processor code	SLAVJ
Processor ARK ID	33916
Processor package size	35 x 35 mm
Country of origin	China

Weight and Dimensions

Depth	267 mm
Width	358 mm
Height	32 mm
Weight	2500 g
