HP Compaq 6730b Overview

Additional software
available from the web
HP SoftPaq Download Manager
HP Client Manager Software
HP Client Management Solutions
Java Card Security for HP ProtectTools
* 60 day trial period for McAfee Total Protection for Small Business software. Internet access required to
receive updates. First update included. Subscription required for updates thereafter.
HP Recovery Manager Each unit is shipped with HP Recovery Manager. HP Recovery Manager enables fast recovery of the
factory preinstalled image if the system becomes corrupted or if important system files are accidentally
deleted. Up to 10 GB of the hard drive is reserved for the system recovery software.
SMBIOS Version 2.4 System Management BIOS, previously known as DMI BIOS, is used to store system management
information.
HP ProtectTools Security
Manager
HP ProtectTools Security Manager is the security platform for business notebooks and desktops. The HP
ProtectTools Security Manager is an extensible client security console that delivers enhanced security
capabilities through add-on software modules. Modules currently available are:
BIOS Configuration for HP ProtectTools
Credential Manager for HP ProtectTools
Device Access Manager for HP ProtectTools
Drive Encryption for HP ProtectTools
File Sanitizer for HP ProtectTools
Set-up Wizard for HP ProtectTools
Privacy Manager for HP ProtectTools (Chat & Sign)
Embedded Security for HP ProtectTools
Java Card Security for HP ProtectTools
Security Standard Features HP ProtectTools Security Manager
Enhanced Pre-Boot Security
HP SpareKey
One-Step Logon
Configuration Control Hardware
Memory Change Alert
Ownership Tag
Setup Password
Power-On Password
TPM 1.2 Embedded Security Chip*
TPM Enhanced DriveLock*
HP Disk Sanitizer
HP 3D DriveGuard
Kensington Lock slot
Support for Computrace / LoJack for Laptops (must be purchased separately)
Optional Features Smart Card Reader
(replaces ExpressCard/54
slot)
Compatible with ISO 7816 compliant Smart
Cards
PC/SC interface support
HP Fingerprint Sensor Enhanced sensor scans the fingerprint to uniquely
identify and authenticate a person
QuickSpecs
HP Compaq 6730b Notebook PC
Standard Features
DA - 13053 Worldwide QuickSpecs — Version 3 — 8.13.2008 Page 10

HP Compaq 6730b Specifications

General

HDD speed	5400 RPM
Optical drive type	DVD Super Multi DL
Card reader integrated	No
Total storage capacity	160 GB
Memory slots	2x SO-DIMM
Internal memory	2 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	8 GB
Bus type	FSB
Stepping	M0
Tjunction	105 °C
Processor cache	3 MB
Processor cores	2
System bus rate	- GT/s
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo P8000 Series
Processor socket	Socket 478
Processor codename	Penryn
Processing Die size	107 mm²
Processor frequency	2.26 GHz
Processor cache type	L2
Processor technology	Intel Centrino 2
Processor lithography	45 nm
Processor manufacturer	Intel
Processor front side bus	1066 MHz
Processor operating modes	64-bit
Thermal Design Power (TDP)	25 W
CPU multiplier (bus/core ratio)	8.5
Number of Processing Die Transistors	410 M
Motherboard chipset	Intel GE45 Express
Display surface	Matt
Display diagonal	15.4 \
Type	PC
Ergonomics	Touch-sensitive controls
LightScribe	Yes
Modem speed	56 Kbit/s
Expansion slots	Slots available for additional devices: 1 ExpressCard/54 slot, Media Card Reader
Power requirements	90W HP Smart AC Adapter, 90W Smart Combo Adapter, HP Fast Charge 6-cell (55 WHr) Lithium-Ion battery, optional HP (52 WHr) Extended Life Battery, optional HP (95 WHr) Ultra-Capacity Battery
Wireless technology	802.11a/b/g/draft-n
Compatible operating systems	Genuine Windows Vista Business 64-bit, Genuine Windows Vista Enterprise, SuSe Linux Enterprise Desktop 10
Audio system	HD
Audio included	High Definition Audio, stereo speakers, stereo headphone/line out, stereo microphone in, integrated microphone (integrated dual-microphone array with optional integrated VGA webcam; VoIP ready)
Networking type	Gigabit Ethernet
Networking features	Broadcom NetLink Gigabit Ethernet PCI Controller (10/100/1000 NIC)
Operating system installed	Windows Vista Business
Number of battery cells	6
I/O ports	4 USB 2.0 ports, VGA, S-video TV out, stereo microphone in, stereo headphone/line out, Firewire (1394a), power connector, RJ-11, RJ-45, serial port
TV-out type	S-Video
Charging port type	DC-in jack
USB 2.0 ports quantity	4
Parallel ports quantity	0
Cable lock slot type	Kensington
Keyboard type	Full-sized
Pointing device	Touchpad + Scroll zone
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Video card features	Mobile Intel Graphics Media Accelerator 4500MHD
Discrete graphics card model	Intel® GMA 4500MHD
Processor code	SL3BU
Processor ARK ID	35569
Processor package size	35 x 35 mm
Country of origin	China

Weight and Dimensions

Depth	266 mm
Width	356 mm
Weight	2700 g
Height (front)	34 mm
