HP Compaq 6730b Overview

1. Docking connector 5. Secondary battery connector
2. WLAN module compartment (select models) 6. SIM slot for WWAN (select models) – inside battery bay
3. Hard drive bay 7. Battery release latch
4. Bluetooth module compartment 8. Battery bay
At A Glance
Genuine Windows Vista Business 32, Genuine Windows Vista Home Basic 32, Genuine Windows Vista Business with
downgrade to Windows XP Professional custom installed, or FreeDOS
Widescreen 15.4-inch diagonal display with wide-viewing angle, optional BrightView and HP Privacy Filter support
Intel® Core™2 Duo processor
Thin, lightweight design starting at 5.93 lb/2.69 kg and 1.32-inch/33.6 mm thin at front
Upgrade Bay for easy optical drive upgrade or optional second hard drive
Flexible wireless connectivity options:
Integrated HP un2400 EV-DO/HSPA Mobile Broadband Module provides worldwide Gobi mobile Internet technology
Integrated 802.11 a/b/g/n draft 2.0 or b/g wireless LAN module
Bluetooth® 2.0
Enhanced security features including HP ProtectTools, HP SpareKey, TPM 1.2; * optional Smart Card Reader and HP
Fingerprint Sensor
Optional integrated VGA webcam with dual-microphone array
HP QuickLook 2 for instant access to e-mail, calendar, and contact information
Up to 250 GB 5400 rpm or 160 GB 7200 rpm user-removable hard drive with HP 3D DriveGuard protection
Enhanced reliability with magnesium alloy support structure and HP DuraFinish
Touch-sensitive controls for HP Info Center/HP QuickLook 2, HP Presentation button, wireless on/off, mute, and volume up,
volume down
Media Card Reader
Up to 8 GB of 800 MHz DDR2 SDRAM supported, dual-channel memory support
Mobile Intel Graphics Media Accelerator 4500MHD
Broadcom NetLink Gigabit Ethernet Controller (10/100/1000 NIC)
Touchpad with scroll zone
QuickSpecs
HP Compaq 6730b Notebook PC
Overview
DA - 13053 Worldwide QuickSpecs — Version 3 — 8.13.2008 Page 3

HP Compaq 6730b Specifications

General

HDD speed	5400 RPM
Optical drive type	DVD Super Multi DL
Card reader integrated	No
Total storage capacity	160 GB
Memory slots	2x SO-DIMM
Internal memory	2 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	8 GB
Bus type	FSB
Stepping	M0
Tjunction	105 °C
Processor cache	3 MB
Processor cores	2
System bus rate	- GT/s
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo P8000 Series
Processor socket	Socket 478
Processor codename	Penryn
Processing Die size	107 mm²
Processor frequency	2.26 GHz
Processor cache type	L2
Processor technology	Intel Centrino 2
Processor lithography	45 nm
Processor manufacturer	Intel
Processor front side bus	1066 MHz
Processor operating modes	64-bit
Thermal Design Power (TDP)	25 W
CPU multiplier (bus/core ratio)	8.5
Number of Processing Die Transistors	410 M
Motherboard chipset	Intel GE45 Express
Display surface	Matt
Display diagonal	15.4 \
Type	PC
Ergonomics	Touch-sensitive controls
LightScribe	Yes
Modem speed	56 Kbit/s
Expansion slots	Slots available for additional devices: 1 ExpressCard/54 slot, Media Card Reader
Power requirements	90W HP Smart AC Adapter, 90W Smart Combo Adapter, HP Fast Charge 6-cell (55 WHr) Lithium-Ion battery, optional HP (52 WHr) Extended Life Battery, optional HP (95 WHr) Ultra-Capacity Battery
Wireless technology	802.11a/b/g/draft-n
Compatible operating systems	Genuine Windows Vista Business 64-bit, Genuine Windows Vista Enterprise, SuSe Linux Enterprise Desktop 10
Audio system	HD
Audio included	High Definition Audio, stereo speakers, stereo headphone/line out, stereo microphone in, integrated microphone (integrated dual-microphone array with optional integrated VGA webcam; VoIP ready)
Networking type	Gigabit Ethernet
Networking features	Broadcom NetLink Gigabit Ethernet PCI Controller (10/100/1000 NIC)
Operating system installed	Windows Vista Business
Number of battery cells	6
I/O ports	4 USB 2.0 ports, VGA, S-video TV out, stereo microphone in, stereo headphone/line out, Firewire (1394a), power connector, RJ-11, RJ-45, serial port
TV-out type	S-Video
Charging port type	DC-in jack
USB 2.0 ports quantity	4
Parallel ports quantity	0
Cable lock slot type	Kensington
Keyboard type	Full-sized
Pointing device	Touchpad + Scroll zone
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Video card features	Mobile Intel Graphics Media Accelerator 4500MHD
Discrete graphics card model	Intel® GMA 4500MHD
Processor code	SL3BU
Processor ARK ID	35569
Processor package size	35 x 35 mm
Country of origin	China

Weight and Dimensions

Depth	266 mm
Width	356 mm
Weight	2700 g
Height (front)	34 mm
