HP Compaq 6730s Getting Started

Getting Started 7
What’s Next?
Backing up
Recovery after a system failure is as complete as your most current backup. You should
create your initial backup immediately after software setup. As you add new software and
data files, you should continue to back up your system on a regular basis to maintain a
reasonably current backup.
Use the Backup and Restore Center to create a backup. Click Start, click All Programs,
click Maintenance, and then click Backup and Restore Center. Follow the on-screen
instructions to back up your entire computer (select models only) or your files.
Recovering
In case of system failure, use the f11 recovery tool to recover your original hard drive image.
✎
The image includes the Windows operating system and software programs installed at
the factory.
Ä
CAUTION: Using f11 will completely erase hard drive contents and reformat the hard drive.
All files you have created and any software installed on the computer will be permanently
removed. The
f11 recovery tool reinstalls the operating system and HP programs and drivers
that were installed at the factory. Software not installed at the factory must be reinstalled.
1. If possible, back up all personal files.
2. If possible, check for the presence of the HP Recovery partition. To find the partition,
click Start, and then click Computer.
✎
If the HP Recovery partition has been deleted, you will need to recover your
operating system and programs using the Windows Vista Operating System DVD
and the Driver Recovery disc (purchased separately). For additional information,
contact technical support. Refer to the “Contacting technical support” section in
the back of this guide.
3. Turn on or restart the computer, and then press esc while the “Press the ESC key for
Startup Menu” message is displayed at the bottom of the screen.
4. Press f11 while the “Press <F11> for recovery” message is displayed on the screen.
5. Follow the on-screen instructions.
✎
Windows Vista provides additional recovery tools through the operating system. For
additional information, go to Help and Support.
✎
If you are unable to boot (start up) your computer, you must purchase a Windows Vista
Operating System DVD to reboot the computer and repair the operating system. For
additional information, contact technical support. Refer to the “Contacting technical
support” section in the back of this guide.

HP Compaq 6730s Specifications

General

Bus type	FSB
Stepping	M0
Tjunction	100 °C
Processor cache	1 MB
Processor cores	2
System bus rate	- GT/s
Processor family	Intel Pentium Mobile
Processor series	Intel Pentium T3000 Series for Mobile
Processor socket	Socket 478
Processor codename	Merom
Processing Die size	143 mm²
Processor frequency	2.16 GHz
Processor cache type	L2
Processor lithography	65 nm
Processor manufacturer	Intel
Processor front side bus	667 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	13
Number of Processing Die Transistors	291 M
Motherboard chipset	Intel® PM45 Express
HDD speed	5400 RPM
HDD interface	SATA
Optical drive type	DVD Super Multi DL
Card reader integrated	Yes
Total storage capacity	250 GB
Display surface	Matt
Display diagonal	15.4 \
Display resolution	1280 x 800 pixels
Native aspect ratio	16:10
Type	PC
Modem speed	56 Kbit/s
Wireless technology	802.11a/b/g/n
Memory slots	2x SO-DIMM
Internal memory	2 GB
Memory clock speed	800 MHz
Internal memory type	DDR2-SDRAM
Maximum internal memory	4 GB
Audio system	HD Audio
Bluetooth version	2.0+EDR
Networking features	Fast Ethernet, WLAN
Operating system installed	FreeDOS
Number of battery cells	6
Charging port type	DC-in jack
Serial ports quantity	0
USB 2.0 ports quantity	4
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 35 °C
Operating relative humidity (H-H)	10 - 90 %
Non-operating relative humidity (non-condensing)	5 - 95 %
AC adapter power	65 W
Pointing device	Touchpad + Scroll zone
Discrete graphics card model	Intel® GMA X4500HD
Processor code	SLB3P
Processor ARK ID	35583
Country of origin	China

Weight and Dimensions

Depth	266 mm
Width	358 mm
Weight	2500 g
Height (front)	32 mm
