HP Compaq 6735b User Manual

SABS Yes
UKRSERTCOMPUTER Yes
† When configured with AMD Turion or AMD Sempron processor
* Configurations of the HP Compaq 6735b that are ENERGY STAR qualified are identified as
HP Compaq 6735b ENERGY STAR on HP websites and on www.energystar.gov .
** EPEAT registration varies by country. See www.epeat.net for registration status by country.
EPEAT status listed above applies to U.S.
NOTE: For accessibility information on HP products, please visit: http://www.hp.com/accessibility .
HP 90W Smart AC Adapter Dimensions 5.00 x 1.97 x 1.1 in (12.7 x 5.0 x 2.9 cm)
Weight 0.82 lb (370 g)
Input 100 to 240 VAC
Input Efficiency 83% min at 115 VAC
Input frequency range 47 to 63 Hz
Input AC current 1.5 A at 90 VAC, 0.75 A at 180 VAC PFC Version
2.4 A at 90 VAC, 1.2 A at 180 VAC NON PFC Version
Output Output power 65W 90W
DC output 19.0V
Hold-up time 5 msec at 115 VAC input
Output current limit <11A, Over voltage protection- 29V max
automatic shutdown
Connector 3 pin/grounded, mates with interchangeable cords
Environmental Design Operating temperature 32° to 104° F (0° to 40° C)
Non-operating (storage)
temperature
–4° to 149° F (–20° to 65° C)
Altitude 0 to 10,000 ft (0 to 3,048 m)
Humidity 20% to 80%
Storage Humidity 10% to 90%
EMI and Safety
Certifications
CE Mark – full compliance with LVD and EMC directives; Worldwide safety
standards – IEC60950, EN60950, UL60950, Class1, SELV; Agency approvals –
C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22 Class B,
CCC, NOM-1 NYCE; MTBF– over 200,000 hours at 25°C ambient condition.
QuickSpecs
HP Compaq 6735b Notebook PC
Technical Specifications
DA - 13055 North America — Version 24 — June 17, 2010 Page 19

HP Compaq 6735b Specifications

General

Processor cache	1 MB
Processor frequency	2.1 GHz
Processor cache type	L2
Motherboard chipset	AMD M780G
HDD speed	5400 RPM
HDD interface	SATA
Optical drive type	DVD Super Multi DL
Card reader integrated	No
Total storage capacity	160 GB
Display diagonal	15.4 \
Display resolution	1280 x 800 pixels
Native aspect ratio	16:10
Type	PC
LightScribe	Yes
Modem speed	56 Kbit/s
Wireless technology	802.11a/b/g/n
Memory slots	2x SO-DIMM
Internal memory	2 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	1 x 2 GB
Audio system	HD Audio
Number of built-in speakers	2
Networking features	Gigabit Ethernet, WLAN
Operating system installed	Windows Vista Business
Number of battery cells	6
TV-out type	S-Video
Charging port type	DC-in jack
USB 2.0 ports quantity	4
Parallel ports quantity	0
Cable lock slot type	Kensington
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
Non-operating relative humidity (non-condensing)	10 - 90 %
AC adapter power	90 W
Discrete graphics card model	AMD Radeon HD 3200
Country of origin	China

Weight and Dimensions

Depth	265 mm
Width	356 mm
Height	33 mm
Weight	2700 g
